Yamaha MX250 2016 - General View (Electric Starting Models)

7
Controls and features
General view (Electric starting models)
1 Fuel tank cap 9 Oil warning light (Red)
2 Air filter case cover 10 Engine switch
3 Carburetor 11 Recoil starter handle
4 Oil drain bolt 12 Throttle lever
5 Oil filler cap 13 Fuel cock cup
6 Spark plug 14 Fuel cock lever
7 Muffler 15 Choke lever
8 Fuel tank 16 Fuel tank filter
8
7
6
5
4
3
2
116
15
14
13
12
11
9
10
