Yamaha MX250 2016 - Air Filter;Foam Element Maintenance

24
Periodic maintenance
6. Add engine oil to the correct level.
7. Install the oil filler cap.
Air filter/foam element
1. Remove the air filter case cover nut and then
remove the air filter case cover.
2. Remove the wing nut and then remove the air filter
assembly.
3. Remove the foam element.
1
0 10 30 50 70 90 110130 °F
-20 -10 0 10 20 30 40 50 °C
SAE 10W-40
SAE 10W-30
1. Correct level
Be sure no foreign material enters the crankcase.
Recommended engine oil:
Recommended oil brand:
YAMALUBE
Available oil grade:
API SE type or higher
JASO MA or MB
Available viscosity index:
10W-30 or 10W-40
Engine oil quantity:
MX250/MX300 1.0 L (1.06 US qt, 0.88 Imp qt)
MX360/MX400 1.1 L (1.16 US qt, 0.97 Imp qt)
NOTICE
1
2
1. Air filter case cover nut
2. Air filter case cover
1
2
1. Wing nut
2. Air filter assembly
12
1. Foam element
2. Air filter
7VE-F8199-70-E0.book 24 ページ ２０１６年１１月１５日 火曜日 午後５時３５分
