Periodic maintenance and adjustment
6-8
6
3. Remove the right floorboard mats
by pulling them up.
4. Remove the bolts, and then pull
the panel outward.
To install the panel
1. Place the panel in the original po-
sition, and then install the bolts.
2. Place the right floorboard mats in
their original position and push
them downward to secure them.
3. Install the bolt and the quick fas-
teners.
4. Install panel A.
1. Bolt
2. Quick fastener
1. Floorboard mat
1. Bolt
