Yamaha P5000S - Circuit Board Layout and Wiring; Circuit Board Layout and Wiring Diagram

8
P5000S/P7000S
■ CIRCUIT BOARD LAYOUT&WIRING（ユニットレイアウト＆結線図）
PAH
PAH
PS
IN
IN
VR
VR
LED
LED
COIL
LED
OUT1
OUT2
OUT2
OUT1
PSW
PSW
The figure which looked at the front panel from the inner side
（フロントパネルを内側から見た図）
Rear Panel（リアパネル）
Front Panel
（フロントパネル）
