Yamaha ProR3 - Reverb + Auto Pan (Rev + PAN)

Advanced uses (2) – Editing functions – 27
ProR3 Digital Reverberator
Reverb + Auto Pan (Rev + PAN)
Common parameters
Key Parameter Value Description
MAIN
REV RevTime 0.3 ~ 99.0 s
Refer to “Reverberation” items on page 18
REV IniDelay 0.1 ~ 200.0 ms
REV HighRatio X0.1 ~ X1.0
REV LowRatio X0.1 ~ X2.4
REV Diffusion 0 ~ 10
PAN Speed 0.05 ~ 40.00 Hz Modulation frequency of auto-pan
PAN Depth 0 ~ 100% Modulation depth of auto-pan
PAN Direction L→R, L←R, L ↔R Direction of panning movement
FINE
PAN/REV Balance *1
*1 Only when REV Patch is parallel (Reverb + PAN)
0/100 ~ 100/0 Level balance of reverb and auto-pan
REV Rev Mix *2
*2 Only when REV Patch is serial (Reverb → PAN, PAN → Reverb)
0 ~ 100% Reverb amount
REV Reverb Type *3
*3 Hall, Room, Vocal, Plate
Type of reverb tone
REV Density 0 ~ 100 Density of reverb
REV HPF Thru, 40 Hz ~ 1.0 kHz Cutoff frequency of reverb high pass filter
REV LPF 400 Hz ~ 20 kHz, Thru Cutoff frequency of reverb low pass filter
REV Space Mod 0 ~ 10 Modulation level of reverb
REV Patch *4
*4 Reverb + PAN, PAN → Reverb, Reverb → PAN
Connection of auto-pan and reverb
Common parameters Refer to “Common parameters” on page 27
Key Parameter Value Description
FINE
1stRef-1 Delay 0.1 ~ 200.0 ms Delay time of reflection 1
1stRef-1 Lvl 0 ~ 100% Level of reflection 1
1stRef-1 Pan L16 ~ R16 Pan position of reflection 1
1stRef-2 Delay 0.1 ~ 200.0 ms Delay time of reflection 2
1stRef-2 Lvl 0 ~ 100% Level of reflection 2
1stRef-2 Pan L16 ~ R16 Pan position of reflection 2
Input Mix *1
*1 Only for stereo mode
0 ~ 100% Stereo-mix adjustment
continues to DFL
