Yamaha PSR-S970 Service Manual

PSR-S770/PSR-S970
4
PSR-S970/S770 Owner’s Manual 111
Specifications
* The contents of this manual apply to the latest specifications as of the printing date. Since Yamaha makes continuous improvements to the product, this manual may
not apply to the specifications of your particular product. To obtain the latest manual, access the Yamaha website then download the manual file. Since
specifications, equipment or separately sold accessories may not be the same in every locale, please check with your Yamaha dealer.
Functions
Songs
Song Creator Yes Yes
Score Display Function Yes Yes
Lyrics Display Function Yes Yes
Text Display Function Yes Yes
Wallpaper Customization Yes Yes
Guide
Follow Lights, Any Key, Karao-Key, Your Tempo Follow Lights, Any Key, Karao-Key, Your Tempo
Performance Assistant
Technology (P.A.T.)
Yes Yes
Multi Pads Multi Pad Creator Yes Yes
Registration
Memory
Number of Buttons
8 8
Control Registration Sequence, Freeze Registration Sequence, Freeze
USB Audio
Player/Recorder
Playback Format
.wav (WAV format: 44.1 kHz sample rate,
16 bit resolution, stereo)
.mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz
sample rate, 64–320 kbps
and variable bit rate, mono/stereo)
.wav (WAV format: 44.1 kHz sample rate,
16 bit resolution, stereo)
.mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz
sample rate, 64–320 kbps
and variable bit rate, mono/stereo)
Recording Format
.wav (WAV format: 44.1 kHz sample rate,
16 bit resolution, stereo)
.wav (WAV format: 44.1 kHz sample rate,
16 bit resolution, stereo)
Recording Time (max.) 80 minutes/Song 80 minutes/Song
Time Stretch Yes Yes
Pitch Shift Yes Yes
Vocal Cancel Yes Yes
Demonstration Yes Yes
Overall Controls
Metronome Yes Yes
Tempo 5 – 500 5 – 500
Transpose -12 – 0 – +12 -12 – 0 – +12
Tuning 414.8 – 440.0 – 466.8 Hz 414.8 – 440.0 – 466.8 Hz
Octave Button Yes Yes
Scale Type 9 types 9 types
Miscellaneous Direct Access Yes Yes
Expandability
(Expansion
Packs)
Expansion Voice Yes (approx. 512 MB max.) Yes (approx. 160 MB max.)
Expansion Style Yes (internal memory) Yes (internal memory)
Expansion Audio Style Yes (approx. 128 MB max.) -
Storage and
Connectivity
Storage
Internal Memory Yes (approx. 13 MB max.) Yes (approx. 13 MB max.)
External Drives USB flash drive USB flash drive
Connectivity
DC IN 16 V 16 V
Headphones Standard stereo phone jack Standard stereo phone jack
Microphone/Guitar Yes Yes
MIDI IN, OUT IN, OUT
AUX IN Stereo mini jack Stereo mini jack
OUTPUT L/L+R, R L/L+R, R
RGB OUT Yes -
FOOT PEDAL
1 (SUSTAIN), 2 (ARTICULATION 1),
Function assignable
1 (SUSTAIN), 2 (ARTICULATION 1),
Function assignable
USB TO DEVICE Yes Yes
USB TO HOST Yes Yes
Amplifiers/
Speakers
Amplifiers 15 W x 2 15 W x 2
Speakers 13 cm x 2 + 2.5 cm (dome) x 2 13 cm x 2 + 5 cm x 2
Power Supply
Power Supply Adaptor
PA-300C or an equivalent recommended
by Yamaha
PA-300C or an equivalent recommended
by Yamaha
Power Consumption 20 W 19 W
Auto Power Off Yes Yes
Included Accessories
• Owner’s Manual
• Online Member Product Registration
• Music rest
•
AC power adaptor* (PA-300C or an equivalent
recommended by Yamaha), power cord*
* May not be included depending on your area.
• Owner’s Manual
• Online Member Product Registration
• Music rest
•
AC power adaptor* (PA-300C or an equivalent
recommended by Yamaha), power cord*
* May not be included depending on your area.
Separately Sold Accessories
(May not be available depending on your area.)
• AC adaptor: PA-300C or an equivalent
recommended by Yamaha
• Headphones: HPE-160/170
• Footswitches: FC4/FC4A/FC5
• Foot controller: FC7
• USB MIDI Interface for iPhone/iPod
touch/iPad: i-UX1
• MIDI Interface for iPhone/iPod touch/
iPad: i-MX1
• USB wireless LAN adaptor: UD-WL01
• USB-MIDI Interface: UX16
• Keyboard stand: L-6/L-7
(The exterior size of the PSR-S970/S770 is
beyond the limits as described in the L-6
Assembly Instructions. However, we have
determined through tests that the stand can be
safely used for the instrument.)
• AC adaptor: PA-300C or an equivalent
recommended by Yamaha
• Headphones: HPE-160/170
• Footswitches: FC4/FC4A/FC5
• Foot controller: FC7
• USB MIDI Interface for iPhone/iPod
touch/iPad: i-UX1
• MIDI Interface for iPhone/iPod touch/
iPad: i-MX1
• USB wireless LAN adaptor: UD-WL01
• USB-MIDI Interface: UX16
• Keyboard stand: L-6/L-7
(The exterior size of the PSR-S970/S770 is
beyond the limits as described in the L-6
Assembly Instructions. However, we have
determined through tests that the stand can be
safely used for the instrument.)
PSR-S970 PSR-S770
12psr_Specifications.fm Page 111 Wednesday, April 8, 2015 12:59 PM

Yamaha PSR-S970 Specifications

General

Polyphony	128 notes
Voices	989 Voices + 41 Drum/SFX Kits + 480 XG Voices
Fingering	Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
Music Finder	Yes
One Touch Setting (OTS)	4 for each style
Display	7-inch TFT Color Wide VGA LCD
Keyboard	61 keys
Effects	Reverb, Chorus, DSP, Master EQ
Styles	450
Style Control	INTRO, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING
Audio Recorder/Player	Recording: WAV (44.1kHz, 16bit, stereo); Playback: WAV (44.1kHz, 16bit, stereo), MP3
Internal Memory	Approx. 13 MB
External Drives	USB Flash Memory
Connectivity	Headphones, MIDI In/Out, USB to Device, USB to Host, AUX In
Speakers	13 cm x 2 + 5 cm x 2
Power Supply	PA-300C or an equivalent recommended by Yamaha
