ELECTRIC STARTING SYSTEM
8-11
EAS27190
TROUBLESHOOTING
The starter motor fails to turn.
TIP
• Before troubleshooting, remove the following part(s):
1. Rider seat
2. Fuel tank
3. Air filter case
4. Side cowlings
5. Thermostat
NG→
OK↓
NG→
OK↓
OK→
NG↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1. Check the fuses.
(Main and ignition)
Refer to “CHECKING THE FUSES”
on page 8-85.
Replace the fuse(s).
2. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-86.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the starter motor operation.
Refer to “CHECKING THE
STARTER MOTOR OPERATION”
on page 8-93.
Starter motor is OK. Perform the elec-
tric starting system troubleshooting,
starting with step 5.
4. Check the starter motor.
Refer to “CHECKING THE
STARTER MOTOR” on page 5-34.
Repair or replace the starter motor.
5. Check the relay unit (starting circuit
cut-off relay).
Refer to “CHECKING THE
RELAYS” on page 8-89.
Replace the relay unit.
6. Check the relay unit (diode).
Refer to “CHECKING THE RELAY
UNIT (DIODE)” on page 8-91.
Replace the relay unit.
7. Check the starter relay.
Refer to “CHECKING THE
RELAYS” on page 8-89.
Replace the starter relay.

Yamaha R6 2009 Specifications

General

Compression Ratio	13.1:1
Fuel Delivery	Fuel injection with YCC-T and YCC-I
Ignition	TCI: Transistor Controlled Ignition
Final Drive	Chain
Rear Brakes	220mm disc; single-piston caliper
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Wheelbase	54.1 in
Seat Height	33.5 in
Fuel Capacity	4.6 gal
Wet Weight	417 lb
Length	80.3 in
Width	27.8 in
Height	43.1 in
Rake (Caster Angle)	24.0°
Trail	3.8 in
Engine Type	Liquid-cooled, inline 4-cylinder, DOHC, 16 valves
Transmission	6-speed
Front Suspension	41mm inverted fork; 4.7-in travel
Rear Suspension	Single shock; 4.7-in travel
Front Brakes	Dual 310mm hydraulic disc; 4-piston calipers
Bore x Stroke	67.0mm x 42.5mm
