4 - 3
ENG
ENGINE
REMOVING THE ENGINE
EBS00207
INSTALLING THE ENGINE
1. Install:
• upper engine mounting bolt/nut
• lower engine mounting bolt/nut
TIP
Do not fully tighten the bolts and nuts.
TIP
The master link clip must be installed with the
rounded end facing the direction of travel.
2. Tighten:
• upper engine mounting nut
• lower engine mounting nut
T
R
.
.
35 Nm (3.5 m · kg, 25.3 ft · lb)
T
R
.
.
35 Nm (3.5 m · kg, 25.3 ft · lb)
1. Remove:
• drive chain
• master link
3. Install:
• drive chain
•
master link
