4 - 46
ENG
OIL PUMP
RemarksOrder Job/Part Q’ty
1
2
3
4
5
6
7
8
9
10
11
12
13
1
2
1
2
1
1
1
1
1
1
1
1
1
Disassembling the oil pump
C.D.I. magneto
Cover
O-ring
Oil seal
Dowel pin
Nut
Oil pump driven gear
Dowel pin
Oil pump body
Outer rotor
Inner rotor
Oil pump shaft
Oil pump housing cover
Dowel pin
Remove the parts in the order listed.
Refer to “ C.D.I. MAGNETO “
For assembly, reverse the disassembly
procedure.
OIL PUMP
3
6
8
9
10
11
7
4
1
13
12
2
LS
5
EBS00315
E
T
R
.
.
12 Nm (1.2 m • kg, 8.7 ft • Ib)
