TF-RACK Quick Guide
1. PRECAUTIONS
Water warning
• Donotexposethedevicetorain,useitnearwaterorin
damp or wet conditions, or place on it any containers (such
as vases, bottles or glasses) containing liquids which might
spill into any openings. If any liquid such as water seeps
into the device, turn off the power immediately and unplug
the power cord from the AC outlet. Then have the device
inspected by qualified Yamaha service personnel.
• Neverinsertorremoveanelectricplugwithwethands.
Hearing loss
• Avoidsettingallequalizercontrolsandfaderstotheir
maximum. Depending on the condition of the connected
devices, doing so may result in feedback that can cause
hearing loss and damage the speakers.
• Donotuseheadphonesforalongperiodoftimeata
high or uncomfortable volume level, since this can cause
permanent hearing loss. If you experience any hearing loss
or ringing in the ears, consult a physician.
• WhenturningontheACpowerinyouraudiosystem,always
turn on the power amplifier LAST, to avoid hearing loss and
speaker damage. When turning the power off, the power
amplifier should be turned off FIRST for the same reason.
Fire warning
• Donotplaceanyburningitemsoropenamesnearthe
device, since they may cause a fire.
If you notice any abnormality
• Ifanyofthefollowingproblemsoccur,immediatelyturnoff
the power switch and disconnect the electric plug from the
outlet.
- The power cord or plug becomes frayed or damaged.
- Unusual smells or smoke are emitted.
- Some object has been dropped into the device.
- There is a sudden loss of sound during use of the device.
- Cracks or other visible damage appear on the device.
Then have the device inspected or repaired by qualified
Yamaha service personnel.
• Ifthisdeviceshouldbedroppedordamaged,immediately
turn off the power switch, disconnect the electric plug from
the outlet, and have the device inspected by qualified
Yamaha service personnel.
CAUTION
Always follow the basic precautions listed below
to avoid the possibility of physical injury to you or
others, or damage to the device or other property.
These precautions include, but are not limited to,
the following:
Power supply/power cord
• Whenremovingtheelectricplugfromthedeviceoran
outlet, always hold the plug itself and not the cord. Pulling
by the cord can damage it.
Location
• Donotplacethedeviceinanunstablepositionwhereit
might accidentally fall over and cause injuries.
• Donotblockthevents.Thisdevicehasventilationholesat
the rear to prevent the internal temperature from becoming
too high. In particular, do not place the device on its
side or upside down. Inadequate ventilation can result in
overheating, possibly causing damage to the device(s), or
even fire.
• Wheninstallingthedevice:
- Do not cover it with any cloth.
- Do not install it on a carpet or rug.
- Make sure the top surface faces up; do not install on its
sides or upside down.
- Do not use the device in a confined, poorly-ventilated
location.
Inadequate ventilation can result in overheating, possibly
causing damage to the device(s), or even fire. If this device is
to be used in a small space other than an EIA-standard rack,
make sure that there is adequate space around the device: at
least 10cm above, 10cm at the sides and 20cm behind.
• Donotplacethedeviceinalocationwhereitmaycomeinto
contact with corrosive gases or salt air. Doing so may result
in malfunction.
• Beforemovingthedevice,removeallconnectedcables.
• IfthedeviceismountedinanEIAstandardrack,carefully
read the section "Rack-mounting the unit" on page 19.
Inadequate ventilation can result in overheating, possibly
causing damage to the device(s), malfunction, or even fire.
Connections
• Beforeconnectingthedevicetootherdevices,turnoffthe
power for all devices. Also, before turning the power of all
devices on or off, make sure that all volume levels are set to
the minimum. Failing to do so may result in electric shock,
hearing loss, or equipment damage.
Maintenance
• RemovethepowerplugfromtheACoutletwhencleaning
the device.
PA-7 1/2
PLEASE READ CAREFULLY
BEFORE PROCEEDING
Please keep this manual in a safe place
for future reference.
WARNING
Always follow the basic precautions listed below to
avoid the possibility of serious injury or even death
from electrical shock, short-circuiting, damages, fire
or other hazards. These precautions include, but are
not limited to, the following:
Power supply/power cord
• Donotplacethepowercordnearheatsourcessuch
as heaters or radiators, and do not excessively bend or
otherwise damage the cord, place heavy objects on it, or
place it in a position where anyone could walk on, trip over,
or roll anything over it.
• Onlyusethevoltagespeciedascorrectforthedevice.The
required voltage is printed on the name plate of the device.
• Useonlythesuppliedpowercord/plug.
If you intend to use the device in an area other than in the
one you purchased, the included power cord may not be
compatible. Please check with your Yamaha dealer.
• Checktheelectricplugperiodicallyandremoveanydirtor
dust which may have accumulated on it.
• Whensettingupthedevice,makesurethattheACoutlet
you are using is easily accessible. If some trouble or
malfunction occurs, immediately turn off the power switch
and disconnect the plug from the outlet. Even when the
power switch is turned off, as long as the power cord is not
unplugged from the wall AC outlet, the device will not be
disconnected from the power source.
• Removetheelectricplugfromtheoutletwhenthedevice
is not to be used for extended periods of time, or during
electrical storms.
• Besuretoconnecttoanappropriateoutletwithaprotective
grounding connection.
Do not open
• Thisdevicecontainsnouser-serviceableparts.Donot
open the device or attempt to disassemble the internal
parts or modify them in any way. If it should appear to be
malfunctioning, discontinue use immediately and have it
inspected by qualified Yamaha service personnel.

Yamaha TF-Rack Specifications

General

Sample rate	48 kHz
Frequency range	20 - 20000 Hz
Channels quantity	40 channels
Channel fader (1kHz)	10 dB
Digital sound processing	24 bit
Headphone out	Yes
Product color	Black
Rack mounting	-
Video capability	No
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	85 W
AUX maximum input	10 dBV
Microphone maximum input	16
Output impedance	75 Ω
Line-in impedance	600 Ω

Weight and Dimensions

Depth	409 mm
Width	480 mm
Height	132 mm
Weight	9200 g
