TF-RACK Quick Guide
4-1 Front panel
1 FADER BANK section
2 iPad connector
3 USB connector
4 MUTE section
5 TAP key
6 CLEAR CUE key
7 USER DEFINED KEYS section
8 PHONES section
4. Panels
9 USER DEFINED KNOBS section
0 Display section
a Ventilation holes
To prevent overheating, do not block the ventilation
holes.
⑦
⑧
⑨⑪
⑩ ② ⑪①
③
④ ⑤
⑥
