9-17
9
8. Install the drain bolts, and then add the
specified amount of the recommended
engine oil. Check the engine oil level and
the vehicle for oil leakage.
TIP
Refer to steps 9–17 of the “To change the en-
gine oil” section for the oil filling procedure.
9. Install the right rear panel by installing the
bolts and quick fastener screws, and
then tighten the bolts to the specified
torque.
1. Torque wrench
1
1. Right rear panel
2. Bolt A
3. Bolt B
4. Bolt C
5. Quick fastener screw
4
1
2
3
5
4
