9-53
9
4. Turn on the main switch, start the engine,
and turn on the electrical circuit in ques-
tion to check if the device operates. If the
fuse blows again immediately, have a
Yamaha dealer check the electrical sys-
tem.
5. Install the hood.
EBU35261
Headlights
This model is equipped with LED headlights.
There are no user replaceable bulbs. If one or
more headlights do not come on, check for a
loose connection, check the headlight fuse,
and then have a Yamaha dealer check the ve-
hicle.
When the headlights are set to low beam,
only the top half of each lamp will illuminate.
When the headlights are set to high beam,
both halves of each lamp will illuminate.
Specified fuses:
Main fuse:
50.0 A
Fuel injection system fuse:
10.0 A
Headlight fuse:
7.5 A
Ignition fuse:
15.0 A
Auxiliary DC jack fuse:
10.0 A
Signaling system fuse:
7.5 A
Four-wheel-drive motor fuse:
7.5 A
Radiator fan motor fuse:
30.0 A
ETV fuse:
10.0 A
Accessory fuse:
20.0 A
Backup fuse:
7.5 A
EPS fuse:
40.0 A
