9-20
9
5. With the arrow mark pointing outward,
fully insert the dipstick into the oil filler
hole and then remove it again.
The oil level should be between the minimum
and maximum level marks.
6. If the oil level is at or below the minimum
level mark, add oil.
Add a sufficient amount to raise to the maxi-
mum level mark, but do not overfill.
7. Install the dipstick.
8. Install the rubber cover.
1. Transmission oil dipstick
2. Maximum level mark
3. Minimum level mark
1. Arrow mark
