INTAKE MANIFOLD
#1
PRESS. SENSOR
THROTTLE BODY
SOLENOID VALVE
#1
#2
ROLL OVER
VALVE
CANISTER
TO ATMOSPHERE
FROM FUEL TANK
VACUUM HOSE ROUTING
EMISSION HOSE ROUTING
BAN-F4897-20
WARNING
• Load or trailer may affect handling and stability.
• Do not exceed the maximum load ratings for the
cargo bed , trailer tongue, or vehicle.
• When loaded with cargo or towing a trailer:
• Reduce speed and allow more room to stop.
• Turn gradually and slowly.
• Avoid hills and rough terrain.
• Secure cargo so that it will not shift - a loose load
could change handling unexpectedly or be thrown
forward and strike occupants.
• Keep weight in the cargo bed centered side to side and
as low as possible. Top-heavy loads increase the risk of a
rollover.
• Do not tow or pull objects from any point other than
the trailer hitch bracket or winch (if installed).
•
Read Owner’s Manual before loading, towing, or pulling objects.
Improper use of cargo area, rear
seats, and/or cage/frame
can result in severe
injury or death from
loss of control, overturn
or other accidents.
Maximum Load in Cargo Bed: 600 lbs (272 kg)
Maximum Vehicle Load: 1160 lbs (525 kg)
Never carry
passengers
in cargo bed.
