Controls and instruments
1 2 5 6 7 83 4
1. Clutch lever (page 4-11)
2. Left handlebar switches (page 4-9)
3. Main switch/steering lock (page 4-1)
4. Multi-function meter unit (page 4-4)
5. Front brake fluid reservoir (page 7-21)
6. Right handlebar switches (page 4-9)
7. Throttle grip (page 7-16)
8. Brake lever (page 4-11)
