Yamaha XSR700M 2021 - License Plate Light

Periodic maintenance and adjustment
7-36
7
3. Remove the burnt-out bulb by
pulling it out.
4. Insert a new bulb into the socket.
5. Install the socket (together with
the bulb) by turning it clockwise.
6. Install the turn signal light unit by
installing the screw. NOTICE: Do
not overtighten the screw, oth-
erwise the lens may break.
[ECA11192]
EAU24331
License plate light
If the license plate light does not come
on, have a Yamaha dealer check the
electrical circuit or replace the bulb.
1. Turn signal light bulb socket
1. Turn signal light bulb
1
1
