Instrument and control functions
4-3
1
2
3
4
5
6
7
8
9
10
11
12
dealer check the electrical circuit.
EAU53885
Multi-function display
WARNING
EWA12313
Be sure to stop the vehicle before
making any setting changes to the
multi-function display. Changing
settings while riding can distract the
operator and increase the risk of an
accident.
The multi-function display is equipped
with the following:
 a speedometer
 an odometer
 two tripmeters
 a fuel reserve tripmeter
 a clock
 a self-diagnosis device
TIP
 Be sure to turn the vehicle on be-
fore using the “SELECT” and “RE-
SET” buttons.
 When the vehicle is turned on, all
of the display segments of the
multi-function display will appear
1. “SELECT” button
2. “RESET” button
3. Clock
4. Speedometer
1
2
3
4
1. Odometer/tripmeter (bottom)/fuel reserve
tripmeter
2. Tripmeter (top)
2
1
