Yamaha XT250 2021 - Page 49

Periodic maintenance and adjustment
7-10
1
2
3
4
5
6
7
8
9
10
11
12
2. Pull the front part of the panel out-
ward, and then remove the panel
by pulling it forward as shown.
To install a panel
Place the collar and panel in their origi-
nal position, and then install the screw.
Panel C
To remove the panel
1. Remove the seat. (See
page 4-10.)
2. Remove the bolt and washer, and
1. Panel A
2. Collar
3. Screw
1. Screw
2. Collar
3. Panel B
3
2
1
1
2
3
1. Panel A
1. Panel B
1
1
1. Panel A
1. Panel B
1
1
