DESCRIPTION
2-3
1. Clutch lever (page 3-4, 6-17)
2. Left handlebar switches (page 3-3)
3. Speedometer unit (page 3-2)
4. Main switch/steering lock (page 3-1)
5. Tachometer (page 3-3)
6. Right handlebar switches (page 3-4)
7. Brake lever (page 3-5, 6-18)
8. Throttle grip (page 6-14)
9. Fuel tank cap (page 3-6)
