6-7
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
EAU00488
Panel B
To remove the panel
Remove the screw, and then pull the
panel off as shown.
To install the panel
Place the panel in the original posi-
tion, and then install the screw.
1. Panel B
2. Screw
1. Spark plug cap
EAU01833
Checking the spark plug
The spark plug is an important
engine component, which is easy to
check. Since heat and deposits will
cause any spark plug to slowly erode,
the spark plug should be removed
and checked in accordance with the
periodic maintenance and lubrication
chart. In addition, the condition of the
spark plug can reveal the condition of
the engine.
To remove the spark plug
1. Remove the spark plug cap.
1. Spark plug wrench
2. Remove the spark plug as
shown, with the spark plug
wrench included in the owner’s
tool kit.
