6-6
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
1
1. Screw
EAU01145
Cowling A
To remove the cowling
Remove the screw, and then pull the
cowling off as shown.
To install the cowling
Place the cowling in the original posi-
tion, and then install the screw.
1
2
EAU00488
Panel A
To remove the panel
Remove the screw, and then pull the
panel off as shown.
To install the panel
Place the panel in the original posi-
tion, and then install the screw.
1. Panel A
2. Screw
