Yamaha XT600E - Left View Component Identification

2-1
EAU00026
DESCRIPTION
Part locations
2
1. Headlight (page 6-33)
2. Fuel cock (page 3-8)
3. Battery (page 6-31)
4. Owner’s tool kit (page 6-1)
5. Helmet holder (page 3-10)
6. Shock absorber spring preload
adjusting nut (page 3-10)
7. Fuse (page 6-32)
8. Starter (choke) knob (page 3-9)
9. Shift pedal (page 3-5)
1 2 3 45
6789
Left view
