6-37
PERIODIC MAINTENANCE AND MINOR REPAIR
6
EAU00897
Front wheel
Removing
To remove the front wheel
EW000122
w
8 It is advisable to have a
Yamaha dealer service the
wheel.
8 Securely support the motorcy-
cle so that there is no danger
of it falling over.
1. Disconnect the speedometer
cable from the front wheel.
1. Speedometer cable
EAU03555
To install the front wheel
Installing
1. Install the speedometer gear unit
into the wheel hub so that the
projections mesh with the slots.
2. Lift the wheel up between the
fork legs.
1. Speedometer gear unit
2. Loosen the wheel axle holder
nuts, then the wheel axle.
3. Lift the front wheel off the ground
according to the procedure on
page 6-36.
4. Pull the wheel axle out, and then
remove the wheel.
ECA00048
cC
Do not apply the brake after the
wheel has been removed together
with the brake disc, otherwise the
brake pads will be forced shut.
1. Wheel axle holder nut (×4)
2. Wheel axle
4PT-E7 (English) 6/29/01 9:13 AM Page 74
