8-4
SPECIFICATIONS
8
Electrical
Ignition system T.C.I. (Digital)
Charging system
Type A.C. magneto
Standard output 14 V, 13.5A @ 5,000 rpm
Battery
Type YTX9-BS
Voltage, capacity 12 V, 8 AH
Headlight bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60/55W × 1
Tail/brake light 12 V, 5/21W × 1
Auxiliary light 12 V, 4W × 1
12 V, 3.4W × 1 (GB only)
Front flasher light 12 V, 21W × 2
Rear flasher light 12 V, 21W × 2
Meter lighting 12 V, 3.4W × 1
Neutral indicator light 12 V, 3.4W × 1
High beam indicator light 12 V, 3.4W × 1
Turn indicator light 12 V, 3.4W × 1
Fuse 20A
