MAINTENANCE SPECIFICATIONS
SPEC
CHASSIS
Item
Standard Limit
Brake lever & brake pedal:
Brake lever free play (at pivot)
Brake lever free play (at lever end)
Brake pedal position
Brake pedal free play
Clutch lever free play (at pivot)
Clutch lever free play (at lever end)
1 X 2 mm
10 X 15 mm
108 mm
20 X 30 mm
2 X 3 mm
10 X 15 mm






