Yamaha XVS650A - CABLE ROUTING; Cable Routing Components

–8–
CABLE ROUTING
SPEC
19 Spark plug lead
20 Fuel pump
10 Sidestand switch lead
11 Rear brake switch lead
12 Horn
13 Headlight lead
14 Right handlebar switch lead
15 Main switch
16 Main switch lead
17 Fuel pump lead
18 Fuel hose
1 Frame
2 Clutch cable
3 Left handlebar switch lead
4 Fuel tank breather hose
5 Speedometer cable
6 Speedometer
7 Speedometer light leads
8 Vacuum chamber air vent hose
9 Rectifier/regulator
EB206000
CABLE ROUTING
