–22–
AIR INDUCTION SYSTEM
CARB
A To the front cylinder head
B To the rear cylinder head
1 Reed valve
2 Air cut valve
3 Air cleaner
4 Carburetor joint
EB601000
CARBURATION
AIR INDUCTION SYSTEM
EAS00509
AIR INDUCTION SYSTEM DIAGRAMS
