Yamaha XVS650A - MAINTENANCE SPECIFICATIONS; Electrical Maintenance Specifications

–5–
MAINTENANCE SPECIFICATIONS
SPEC
ELECTRICAL
Item
Standard Limit
T.C.I.:
Pickup coil resistance/color
T.C.I. unit model/manufacturer
182 X 222 Ω at 20C/Gray – Black
J4T094/MITSUBISHI


Ignition coil:
Model/manufacturer
Minimum spark gap
Primary winding resistance
Secondary winding resistance
F6T541/MITSUBISHI
6 mm
3.6 X 4.8 Ω at 20C
10.7 X 14.5 kΩ at 20C




Voltage regulator:
Type
Model/manufacturer
No load regulated voltage
Semi-conductor, short-circuit type
SH650C-11/SHINDENGEN
14.1 X 14.9 V



Rectifier:
Model/manufacturer
Capacity
Withstand voltage
SH650C-11/SHINDENGEN
18 A
200 V



Electric starter system:
Type
Starter motor:
Model/manufacturer
I.D. number
Output
Brush overall length
Commutator diameter
Mica undercut
Starter relay:
Model/manufacturer
Amperage rating
Constant mesh type
SM-13/MITSUBA
SM-13
0.7 kW
10 mm
28 mm
0.7 mm
MS-5F-441/JIDECO
180 A




4 mm
27 mm



Flasher relay:
Type
Model/manufacturer
Self cancelling device
Flasher frequency
Wattage
Full transistor type
FE246BH/DENSO
No
75 X 95 cycle/min
21 W 2 + 3.4 W





Fuel pump relay:
Model/manufacturer
G8R-30Y-Q/OMRON

