–28–
FRONT BRAKE
CHAS
***************************************
 Loosen the brake caliper bleed screw and
using a finger push the caliper pistons into
the brake caliper.
 Tighten the brake caliper bleed screw
2
.
Brake caliper bleed screw:
6 Nm (0.6 mkg)
 Install new brake pads and a new brake pad
spring.
 Install the brake caliper
3
and retaining bolt
4
.
Bolt (brake caliper):
40 Nm (4.0 mkg)
Retaining bolt:
27 Nm (2.7 mkg)
4. Check
 Brake fluid level
Refer to “BRAKE FLUID LEVEL INSPEC-
TION” in CHAPTER 3.
a
“LOWER” level line
5. Check:
 Brake lever operaiton
Soft or spongy feeling  Bleed the brake
system.
Refer to “AIR BLEEDING (HYDRAULIC
BRAKE SYSTEM)” in CHAPTER 3.
