Pin
No.
Port Name
Function
Name
(P.C.B.)
I/O
Detail of Function
Power On
Standby /
[Stby AW] / (iPod)
Stby HDMI /
[Stby CEC]
When Apply Current
1 PK6 DIR_SDO2 I I CDDA writing data input
PK6/AN14
2 PK7 TI_WARNG I+ HiZ DAMP error detect input
PK7/AN15 P.U to +3.3D
3 AVSS AVSS MCU MCU MCU
4 VREFH VREFH MCU
5 RESETn N_RESET MCU uCOM RESET input / Processed in microprocessor, usually pull-up
6 MODE MODE MCU Connected to GND / Processed in microprocessor, usually pull-up
7 SDA0 / PL0/ PWM_SDA SIO HiZ PWM_MOD I2C data input/output
SDA0/TB0OUT P.U to +3.3D
8 SCL0 / PL1/ PWM_SCL SO HiZ PWM_MOD I2C data clock output
SCL0/TB1OUT P.U to +3.3D
9 PL2 PWM_N_PDN O O PWM_MOD power down output
PL2/SCK0/TB2OUT
10 INT0 TUNER_GPIO IRQ HiZ TUNER GPIO input (INT pulse 1uS:RDS/SEEK detect)
PL3/INT0/TB3OUT P.U to +3.3D
11 PL4 PWM_N_RST O O PWM_MOD reset output
PL4/TXD1/TB4OUT P.U to +3.3D
12 PL5 PWM_N_MUTE O O PWM_MOD mute output
PL5/RXD1/TB5OUT P.U to +3.3D
13 PL6 D4_N_WARNG I+ HiZ D4 protection / Processed in microprocessor, usually pull-up
PL6/SCLK1/TB6OUT/CTS1n P.U to +3.3D
14 INT1 AC_PON_DET IRQ IRQ AC Interrupt input to detect connection
PL7/INT1/TB7OUT
15 DVSS DVSS MCU MCU MCU
16 SCLK2 D4_SCK SO O D4 synchronous clock
PM0/SCLK2/TB1IN0/CTS2n
17 TXD2 D4_MOSI SO O D4 synchronous data output
PM1/TXD2/TB1IN1
18 RXD2 D4_MISO SI HiZ D4 synchronous data input
PM2/RXD2/ALARMn
19 PM3 D4_N_CS O O D4 chip select output
PM3/INT2
20 PM4 D4_N_RST O O D4 reset output
PM4/SCLK3/CTS3n
21 PM5 D4_N_DISABLE O O D4 PWM stop
PM5/TXD3
22 PM6 D4_PON O O D4 power ON/OFF
PM6/RXD3
23 INT3 FLASH_RXD IRQ IRQ FLASH_UART/232C (asynchronous communication) mode data input
PM7/INT3 (C1 interrupt) / Parallel input
24 TXD4 FLASH_TXD SO SO FLASH_UART/232C (asynchronous communication) mode data output
PN0/TXD4
25 RXD4 FLASH_RXD SI SI FLASH_UART/232C (asynchronous communication) mode data input
PN1/RXD4 Parallel input
26 PN2 232C_CTS I I 232C transmission enable input
PN2/SCLK4/TB2IN0/CTS4n
27 INT4 DIR_N_INT IRQ IRQ DIR interrupt input
PN3/INT4/TB2IN1/RMIN0
28 TXD5 DSP_MOSI SO O DSP/DIR synchronous data output
PN4/TXD5
29 RXD5 DSP_MISO SI HiZ DSP/DIR synchronous data input
PN5/RXD5
30 SCLK5 DSP_SCK SO O DSP/DIR synchronous clock
PN6/SCLK5/TBFIN0/CTS5n
31 INT8 DSP1_N_INT IRQ IRQ DSP1 interrupt input
PN7/INT8/TBFIN1/RMIN1
32 PO0 D4_N_IRQ I HiZ D4 IRQ input
PO0/TXD6/TB8OUT
33 PO1 DIR_N_CS O O DIR chip select output
PO1/RXD6/TB9OUT
