■ Amplifier Section /
アンプ部
Rated Output Power /
定格出力
(1 % THD)
SUBWOOFER (100 Hz)
[YSP-CU4300] (4 ohms) ...............................124 W (62 W x 2)
[YSP-CU3300] (6 ohms) .................................90 W (45 W x 2)
TWEETER (1 kHz, 4 ohms)
[YSP-CU4300] .............................................................. 37.4 W
[YSP-CU3300] .............................................................. 27.2 W
Maximum Effective Output Power /
実用最大出力
(JEITA, 10 % THD)
SUBWOOFER (100 Hz)
[YSP-CU4300] (4 ohms) ...............................150 W (75 W x 2)
[YSP-CU3300] (6 ohms) ...............................100 W (50 W x 2)
TWEETER (1 kHz, 4 ohms)
[YSP-CU4300] ................................................................. 44 W
[YSP-CU3300] ................................................................. 32 W
Total Maximum Output Power /
総合最大出力
[YSP-CU4300] .............................. 194 W (2 W x 22 + 75 W x 2)
[YSP-CU3300] .............................. 132 W (2 W x 16 + 50 W x 2)
Maximum Input Signal /
最大許容入力
(1 kHz)
Analog input (DSP through) ....................................2.2 V or less
Total Harmonic Distortion /
全高調波歪率
(20k L.P.F., 1 kHz)
SUBWOOFER
[YSP-CU4300] (4.4 V, 4 ohms) ..........................0.05 % or less
[YSP-CU3300] (5.0 V, 6 ohms) ..........................0.05 % or less
TWEETER (1.0 V, 4 ohms) ....................................0.08 % or less
■ HDMI Section /
HDMI 部
HDMI Specification /
HDMI 規格
................................................................................Version 1.4a
Content Protection /
著作権保護
......HDCP (High-bandwidth Digital Content Protection system)
Audio Format /
音声フォーマット
...................................HD audio, SD audio, M-ch LPCN, Stereo
Video Format /
映像フォーマット
................................................ Up to 4K (4,096 x 2,160p/24Hz)
Link Function /
リンク機能
.............................................................................. HDMI control
Based on version 1.4a audio control
Auto Lip Sync /
オートリップシンク
...........................................................................max. 500 msec
ARC Function /
ARC 機能
................................................................Audio Return Channel
Based on version 1.4a
■ SPECIFICATIONS /
参考仕様
■ FM Tuner Section /
FM チューナー部
[YSP-CU4300]
Tuning Range /
受信周波数範囲
U, C models .................................................. 87.5 to 107.9 MHz
T, K, A, B, G, F, L, V, S, H models .............. 87.50 to 108.00 MHz
J model ........................................................... 76.0 to 90.0 MHz
Frequency Step /
周波数ステップ
U, C models .................................................................. 200 kHz
T, K, A, B, G, F, L, V, S, H models .................................... 50 kHz
J model ......................................................................... 100 kHz
Antenna Input /
アンテナ入力
................................................................ 75 ohms unbalanced
■ Speaker Section /
スピーカー部
SUBWOOFER L/R
Type /
型式
......................................... Acoustic suspension type /
密閉型
Driver /
スピーカーユニット
(Full-range)

...........................................6.5 x 10 cm (2-1/2" x 3-7/8") cone
Non-magnetic shielding type x 2
6.5x10cm コーン非防磁型x2
Frequency Response /
再生周波数帯域
(*1)
.....................................................................160 Hz to 22 kHz
Impedance /
インピーダンス
[YSP-CU4300] ..............................................................4 ohms
[YSP-CU3300] ..............................................................6 ohms
TWEETER
Type /
型式
......................................... Acoustic suspension type /
密閉型
Driver /
スピーカーユニット
[YSP-CU4300] .........................................2.8 cm (1-1/8") cone
Magnetic shielding type x 22
2.8cm コーン防磁型x22
[YSP-CU3300] .........................................2.8 cm (1-1/8") cone
Magnetic shielding type x 16
2.8cm コーン防磁型x16
Frequency Response /
再生周波数帯域
(*1)
.....................................................................500 Hz to 22 kHz
Impedance /
インピーダンス
.....................................................................................4 ohms
*1 Frequency of total sets
(YSP-CU4300 or YSP-CU3300 and NS-WSW160)
Frequency Response /
再生周波数帯域
..................................................................30 Hz to 22 kHz
Crossover Frequency /
クロスオーバー周波数
........................................160 Hz (stereo play back mode)
160 Hz, 500 Hz (surround play back mode)
YSP-CU4300 YSP-CU3300
