908 (35-3/4")
1002 (39-1/2")
86
(3-3/8")
51
(2")
79
(3-1/8")
30
(1-1/8")
161 (6-3/8") 160 (6-1/4")
99.5
(3-7/8")
(with SPACER / スペーサーを含む )
(without SPACER /
スペーサーを除く )
Front view
Top view
Unit: mm (inch)
単位
：mm（インチ）
YSP-CU3300
446 (17-1/2") 435 (17-1/8")
435 (17-1/8")
145 (5-3/4")
135 (5-3/8")
146
(5-3/4")
371 (14-5/8")
245 (9-5/8")65
(2-1/2")
40 (1-5/8")
335 (13-1/4")50
(2")
50
(2")
ø 60
85
(3-3/8")
30
(1-1/8")
30 (1-1/8")
ø 60
245 (9-5/8")40
(1-5/8")
65 (2-1/2")
Front view Bottom view
Front view
Top view
Upright position
Horizontal position
NS-WSW160
Unit: mm (inch)
単位：mm（インチ）
21
YSP-CU4300/YSP-CU3300/NS-WSW160
YSP-CU4300/YSP-CU3300/
NS-WSW160
