Pin
No.
Function
Name
Type I/O Detail of Function
12 R0X0-
13 R0X0+
14 R0X1-
TMDS Input
HDMI receiver Port 0 TMDS input data
pairs.
15 R0X1+
16 R0X2-
17 R0X2+
10 R0XC-
TMDS Input
HDMI receiver Port 0 TMDS input clock
pair.
11 R0XC+
22 R1X0-
23 R1X0+
24 R1X1-
TMDS Input
HDMI receiver Port 1TMDS input data
pairs.
25 R1X1+
26 R1X2-
27 R1X2+
20 R1XC-
TMDS Input
HDMI receiver Port 1 TMDS input clock
pair.
21 R1XC+
30 R2X0-
31 R2X0+
32 R2X1-
TMDS Input
HDMI receiver Port 2 TMDS input data
pairs.
33 R2X1+
34 R2X2-
35 R2X2+
28 R2XC-
TMDS Input
HDMI receiver Port 2 TMDS input clock
pair.
29 R2XC+
41 R3X0-
42 R3X0+
43 R3X1-
TMDS Input
HDMI receiver Port 3 TMDS input data
pairs.
44 R3X1+
45 R3X2-
46 R3X2+
39 R3XC-
TMDS Input
HDMI receiver Port 3 TMDS input clock
pair.
40 R3XC+
49 R4X0-
50 R4X0+
51 R4X1-
TMDS Input
HDMI receiver Port 4 TMDS input data
pairs.
52 R4X1+
53 R4X2-
54 R4X2+
47 R4XC-
TMDS Input
HDMI receiver Port 4 TMDS input clock
pair.
48 R4XC+
59 R5X0-
60 R5X0+
61 R5X1-
TMDS Input
HDMI receiver Port 5 TMDS input data
pairs.
62 R5X1+
63 R5X2-
64 R5X2+
57 R5XC-
TMDS Input
HDMI receiver Port 5 TMDS input clock
pair.
58 R5XC+
Pin
No.
Function
Name
Type I/O Detail of Function
137 ARC0
Analog
Input/
Output
Audio Return Channels 0 and 1.
These pins are used to transmit or
receive an IEC60958-1 audio stream.
In ARC transmitter mode, received
on the SPDIFn_IN input pin, this pin
transmits an S/PDIF signal to an ARC
receiver-capable source (such as HTiB)
or a repeater (such as AVR) devices,
using single-mode ARC.
138 ARC1
In ARC receiver mode, transmitted
through the SPDIFn_OUT pin, this pin
receives an S/PDIF signal from an ARC
transmitter-capable sink (such as DTV)
device, using single-mode ARC. In
combination with external components,
common-mode ARC can be received.
Each channel can either be an ARC
input or an ARC output at one time.
Pin
No.
Function
Name
Type I/O Detail of Function
154 T0X0-
155 T0X0+
HDMI transmitter Port 0 TMDS output
data pairs.
156 T0X1-
TMDS Output
157 T0X1+
Main HDMI transmitter output Port
TMDS data pairs.
158 T0X2-
159 T0X2+
152 T0XC-
TMDS Output
HDMI transmitter Port 0 TMDS output
clock pair.
153 T0XC+
Main HDMI transmitter output Port
TMDS clock pair.
144 T1X0-
145 T1X0+
HDMI transmitter Port 1 TMDS output
data pairs.
146 T1X1-
TMDS Output
147 T1X1+
Sub HDMI transmitter output Port
TMDS data pairs.
148 T1X2-
149 T1X2+
142 T1XC-
TMDS Output
HDMI transmitter Port 1 TMDS output
clock pair.
143 T1XC+
Sub HDMI transmitter output Port
TMDS clock pair.
HDMI Receiver and MHL Port Pins HDMI Transmitter Port Pins
Audio Return Channel Pins
Note: For Port 0 and Port 5 that have been configured as MHL inputs, the
R0X0+ and R0X0- pin pair and R5X0+ and R5X0- pin pair carry the
respective MHL signals.
