INSTRUMENT AND CONTROL FUNCTIONS
3-4
3
If the tachometer displays such an er-
ror code, note the circuit-specific num-
ber of r/min, and then have a Yamaha
dealer check the motorcycle.
EC000004
CAUTION:
@
When the tachometer displays an
error code, the motorcycle should
be checked as soon as possible in
order to avoid engine damage.
@
EAU01652
Coolant temperature gauge
With the key in the “ON” position, the
coolant temperature gauge indicates
the temperature of the coolant. The
coolant temperature varies with chang-
es in the weather and engine load. If
the needle reaches or enters the red
zone, stop the motorcycle and let the
engine cool. (See page 6-47 for further
instructions.)
EC000002
CAUTION:
@
Do not operate the engine if it is
overheated.
@
1. Coolant temperature gauge
2. Coolant temperature gauge red zone
