7 - 56
CHAS
EB703002
Order
Job/Part
Q’ty
Remarks
Disassembling the front fork legs
Remove the parts in the order listed.
The following procedure applies to
both of the front fork legs.
1
Cap
bolt/O-ring
1/1
2
Straight
key
1
3
Washer
1
4
Damper adjusting rod
1
5
Nut
1
6
Spring
seat
1
7
Spacer
1
8
Fork spring
1
9
Outer
tube
1
0
Dust seal
1
A
Oil seal clip
1
B
Oil
seal
1
C
Washer
1
FRONT FORK
305
307
