7 - 86

CHAS

EB707700

INSTALLING THE SWINGARM

1. Lubricate:

• bearings

• spacers

• dust covers

• pivot shaft

2. Install:

• spacers

• swingarm

• pivot shaft bosses

• pivot shaft

• washer

• pivot shaft nut

3. Install:

• drive chain pullers

NOTE:

Install the drive chain pullers onto the

swingarm so that the sides stamped

“IN” face toward the inside (i.e., the rear

wheel).

4. Install:

• rear shock absorber assembly

• rear wheel

Refer to “REAR SHOCK ABSORBER

ASSEMBLY” and “REAR WHEEL”.

5. Adjust:

• drive chain slack

Refer to “ADJUSTING THE DRIVE

CHAIN SLACK” in chapter 3.

Recommended lubricant

Molybdenum disulfide grease

Drive chain slack

40 ~ 50 mm (1.57 ~ 1.97 in)

125 Nm (12.5 m · kg, 90 ft · lb)

SWINGARM AND DRIVE CHAIN
