Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
134
8E)
• 1:1 Connection
• 1:n Connection
Signal name
RDB
SDB
SG
TERM
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Terminal block
Shield
Terminal block
Controller
RDA
SDA
Signal name
DA
DB
SG
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
User-created cable
Signal name
RDB
SDB
SG
TERM
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Terminal block
Shield
Terminal block
Controller
RDA
SDA
Signal name
DA
DB
SG
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
User-created cable
