Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
73
Settings of External Device
Use the ladder software (Smart Loader Package SLP-CM1 V2.0.1) to configure communication settings for the
External Device. Use the rotary switch on the front of the Controller to set the device address and transmission
speed of the External Device.
Refer to your Controller manual for details.
Procedure
1 Set the device address and transmission speed using the rotary switch on the front of the Controller, as shown
below.
After setting them, reboot the External Device.
2 Start the ladder software and select [Setup].
3
Select [Communication] - [Host] in the tree view and set [Data format] as shown below.
4 Select [Write (SLP10 to CMC10B)] from the [Communication] menu, and download the set data to the External
Device.
5 Reboot the External Device.
Rotary Switch Settings
CMC ADDRESS (x10) 0
CMC ADDRESS (x1) 1
HOST
←→ CMC BRATE 2
Setup Items Settings
Data format 0
The parameters to be set vary depending on the Controller. Refer to your Controller manual
for details.
