Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
97
4A)
• 1:1 Connection
• 1:n Connection
• No termination resistor is required.
• No termination resistor is required.
Signal name
RDB
SDB
SG
TERM
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Shield
RDA
SDA
DA
DB
SG
Terminal block
Signal name
Controller
User-created cable
Signal name
RDB
SDB
SG
TERM
CA3-ADPCOM-01
CA3-ADPTRM-01
Display
Shield
RDA
SDA
DA
DB
SG
Shield
DA
DB
SG
Terminal block
Signal name
Controller
Terminal block
Signal name
Controller
User-created cable
