Yamatake SDC40A Series - Cable Diagram 2 (RS422;485 4-wire)

Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
81
Cable Diagram 2
Display
(Connection Port)
Cable Remarks
GP3000
*1
(COM1)
AGP-3302B (COM2)
ST
*2
(COM2)
LT (COM1)
IPC
*3
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
*3 Available only with COM ports that support RS-422/485 (4wire).
) IPC COM Port (page 7)
2A
COM port conversion adapter by Pro-face.
CA3-ADPCOM-01
+
Connector terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
Cable length:
500m or less
2B User-created cable
GP3000
*4
(COM2)
*4 All GP3000 models except the GP-3200 Series and AGP-3302B
2C
Online adapter by Pro-face
CA4-ADPONL-01
+
Connector terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
2D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created cable
GP-4106 (COM1) 2E User-created cable
