Yanmar 2YM15 - Damper Disc

5. Inspection and servicing of basic engine parts
133
5.8.2 Damper disc
(1) Spline part
Whenever uneven wear and/or scratches are found,
replace with new one.
(2) Spring
Whenever uneven wear and/or scratches are found,
replace with new one.
(3) Pin wear
Whenever uneven wear and/or scratches are found,
replace with new one.
(4) Whenever a crack or damage to the spring
slot is found, replace the defective part with
new one.
Spline
Spring
Pin
