Yanmar 2YM15 - Glow Plug

12. Electrical System
199
12.8 Glow plug
A glow plug is available for warming intake air when
starting in cold areas in winter. The glow plug is
mounted to the cylinder head. The device is operated
by the glow switch on the instrument panel.
Rated current 8-10A
Rated voltage DC11V
69
17.25
18.5
12 mm
-0.3
0
118.5
M4 x 0.7
Hexagon subtense
M10 x 1.25
(Glow plug)
Glow connector
Glow plug
Cylinder head
