2. Inspection and adjustment
33R1
(6) Replace the fresh water coolant.
Be sure to replace the fresh water every year. When the long life coolant is used of the specified type,
the replacement period of two years can be obtained.
Use clean soft water and be sure to add the Long Life Coolant Antifreeze (LLC) to the cooling water in
order to prevent rust built up and freezing.
Cooling performance drops when cooling water is contaminated with rust and scale.
Even if antifreeze or antirust is added, the cooling water must be replaced periodically because the
properties of the agent will degenerate.
1) Open the two cocks for fresh water and extract the fresh water.
Note:
One drain cock is behind the belt cover. Remove the belt cover and open the cock.
2) Close the two cocks for fresh water.
3) Remove the filler cap of the fresh water cooler by
turning the cap counterclockwise 1/3 of a turn.
4) Pour cooling water slowly into the coolant tank so that air bubbles do not develop. Pour until the
water overflows from the filler port.
If the filler cap is loose, hot steam and water will spout out which may
cause burns.
Fresh water line Seawater line
22
Coolant tank
Fresh water
pump
Seawater pump
Drain plug for seawater
Drain cock
for seawater
Drain plug for coolant
Drain cock for coolant
Tabs
Pressue cap
Fresh water
supply port
Coolant tankNotches
007532-00E
