2. Inspection and adjustment
36R1
(10) Check the wiring connectors.
Check whether each connection part doesn't have loosened.
0
20
10
30
40
GLOW
B
OFF
ON
START
STOP
50
Battery switch
Battery
Alternator
(Fitting to marine gear)
Neutral safety switch
B-type panel
Extension
wire harness
To earth bolt
Starting motor
Stop solenoid
To lube switch and
fresh water switch
Safety
relay
Glow relay
Glow connector
Glow plug
Magnet relay
