5. NAMES AND FUNCTIONS OF COMPONENTS
SA221/324/424 Operation Manual
(25)2WD/4WD lever
Engages or disengages the 4-wheel drive.
(A) 2WD/4WD lever
(a) Disengage position
(b) Engage position
●Always exercise extreme caution while
operating the tractor on slopes.
●Enable the 4-wheel drive in order to increase
traction as necessary.
●While the 4-wheel drive can improve access to
terrain with dangerous slopes, the danger of
tipping over is still present.
IMPORTANT
●Always disengage the 4-wheel drive during
driving on a paved surface.
●Engage to the 4-wheel drive only as required to
prevent premature wear on the front tires.
●Avoid under any circumstances using tire chains
on the tractor's front wheels, because the tire
chains can be thrown against the tractor and
cause damage.
