PERIODIC MAINTENANCE
SD60 Operation Manual 25
4. Using low pressure pump, add oil.
3L-SAE 15W-40
Figure 7
5. Replace the O-rings on the oil cap sail
drive, lubricate it and prepare to
reassemble it.
Figure 8
6. Screw in the oil dipstick and tighten by
hand.
Figure 9
