Step 18: Secure Roof Peak Brackets
A: Tighten the two screws in Roof Peak Brackets then attach to (729) Corner LTs and (737) Corner RTs in the
remaining holes with fourteen #10 x 1-1/4” Pan Screws. (g. 18.1)
Hardware
14 x #10 x 1-1/4” Pan Screw
Fig. 18.1
Roof Peak
Bracket
Roof Peak
Bracket
#10 x 1-1/4”
Pan Screw x 14
Corner
LT & RT
Corner
LT & RT
Corner
LT & RT
Corner
LT & RT
