YASKAWA CDBR-****D

3 Receiving
14 YASKAWA ELECTRIC TOBP C720600 01E YASKAWA AC Drive Option CDBR-D, LKEB- Installation Manual
■ LKEB Braking Resistor Unit
Voltage Class No.
Max. Motor
Capacity (kW)
Average Dissipated
Power (W)
Resistance (Ω)
2200 V
0P7 0.75 70 200
1P5 1.5 260 100
2P2 2.2 260 70
3P7 3.7 390 40
5P5 5.5 520 30
7P5 7.5 780 20
011 11 2400 13.6
015 15300010
018 18.5 4800 8
022 22 4800 6.8
4400 V
0P7 0.75 70 750
1P5 1.5 260 400
2P2 2.2 260 250
3P7 3.7 390 150
5P5 5.5 520 100
7P5 7.5 780 75
011 11 1040 50
015 15156040
018 18.5 4800 32
022 22 4800 27.2
030 30600020
037 37960016
045 45 9600 13.6
LKEB- 2 0P7
Braking Resistor Unit
