YASKAWA ELECTRIC TOBP C720600 01E YASKAWA AC Drive Option CDBR-D, LKEB- Installation Manual 9
2 Product Overview
2 Product Overview
◆ About this Product
CDBR Braking Units and LKEB Braking Resistor Units helps dissipate regenerative energy
from the motor. This is useful in applications that require sudden deceleration and frequent
stops and it allows for shorter deceleration times in applications running heavy loads.
◆ Applicable Models
■ CDBR Braking Unit
The CDBR Braking Unit is designed for use with the drive models in Table 1. It can also
replace a spec B type CDBR. Contact Yaskawa or your Yaskawa agent for more information
or to use the CDBR on drives not listed.
Table 1 CDBR Braking Unit Applicable Models
Drive Series Models
Varispeed G7
CIMR-G72018 to 2110
CIMR-G74018 to 4300
A1000
CIMR-A2A0169 to 2A0415
CIMR-A4A0088 to 4A1200
CIMR-A5A0062 and 5A0077
T1000A
CIMR-T2A0169 to 2A0415
CIMR-T4A0088 to 4A0362
L1000A
CIMR-L2A0145 to 2A0415
CIMR-L4A0075 to 4A0216
H1000 CIMR-H4A0075 to 4A1090
GA700
CIPR-GA702
CIPR-GA704
CH700
CIPR-CH702
CIPR-CH704
CR700
CIPR-CR702
CIPR-CR704
TOBP_C720600_01E_9_0_E.book 9 ページ ２０１７年８月２５日 金曜日 午後２時８分
